Mae dimensiynau a chatalog ffitiadau pibellau NPT yr un peth gan wahanol gyflenwyr.
Deunydd Mathau o ffitiadau pibellau fel dur gwrthstaen, pres a phlastig.
Cymhwyso ffitiadau pibellau edau NPT y DU ac UDA mewn ffitiadau pibellau offeryniaeth a ffitiadau pibellau diwydiannol.
Addaswyr ffitiadau pibell NPT i weldio soced, benyw NPT, SAE ORB, gwryw BSPT, gwryw ORFS, cysylltydd tiwb DIN 2353, o-ring metrig ac ati.
Siâp addasydd pibell NPT fel syth, Penelin, Tee, Cross, Reducer.
Gallwn hefyd gyflenwi ffitiadau bsp hyd at 2 fodfedd.
Siart maint cysylltydd pibell 5NO NPT MALE / SAE FEMALE ISO 11926-1 fel a ganlyn:
PA RT N O. | T HR EA D. | DIM E N S I O NS | |||
E. | F. | A. | L. | S 1 | |
5N O- 02 - 04 | Z 1/8 " X 27 | 7/16 " X 20 | 10.5 | 29.5 | 17 |
5N O- 02 - 05 | Z 1/8 " X 27 | 1/2 " X 20 | 10.5 | 30.5 | 17 |
5N O- 04 | Z 1/4 " X 18 | 7/16 " X 20 | 15 | 34 | 17 |
5N O- 04 - 06 | Z 1/4 " X 18 | 9/16 " X 18 | 15 | 36 | 19 |
5N O- 04 - 08 | Z 1/4 " X 18 | 3/4 " X 16 | 15 | 41 | 27 |
5N O- 06 - 04 | Z 3/8 " X 18 | 7/16 " X 20 | 16 | 22 | 19 |
5N O- 06 | Z 3/8 " X 18 | 9/16 " X 18 | 16 | 34.5 | 19 |
5N O- 06 - 08 | Z 3/8 " X 18 | 3/4 " X 16 | 16 | 40 | 24 |
5N O- 08 - 06 | Z 1/2 " X 14 | 9/16 " X 18 | 19.5 | 27.5 | 24 |
5N O- 08 | Z 1/2 " X 14 | 3/4 " X 16 | 19.5 | 41.5 | 27 |
5N O- 08 - 10 | Z 1/2 " X 14 | 7/8 " X 14 | 19.5 | 46.5 | 30 |
5N O- 12 - 08 | Z 3/4 " X 14 | 3/4 " X 16 | 19.5 | 29.5 | 30 |
5N O- 12 - 10 | Z 3/4 " X 14 | 7/8 " X 14 | 19.5 | 42.5 | 30 |
5N O- 12 | Z 3/4 " X 14 | 1.1 / 16 " X 12 | 19.5 | 47 | 36 |
5N O- 16 - 12 | Z 1 " X 11.5 | 1.1 / 16 " X 12 | 25.5 | 36.5 | 36 |
5N O- 16 | Z 1 " X 11.5 | 1.5/16 " X 12 | 25.5 | 53 | 41 |
5N O- 20 | Z 1.1 / 4 " X 11.5 | 1.5/8 " X 12 | 26.5 | 55.5 | 50 |
Tagiau poblogaidd: addasydd sae i npt, China, gweithgynhyrchwyr, cyflenwyr, arfer, pres, swagelok, Parker, Stauff, Brennan, dur gwrthstaen
